Camera
Image Sensor
2 MP CMOS
Max. Resolution
1920 (H) × 1080 (V)
Min. Illumination
0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
Shutter Time
PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
Day & Night
24/7 Color Imaging
Angle Adjustment
Pan: 0 to 360°, Tilt: 0 to 180°, Rotation: 0 to 360°
Signal System
PAL/NTSC
Lens
Lens Type
2.8 mm, 3.6 mm and 6 mm fixed focal lens
Focal Length & FOV
2.8 mm, horizontal FOV: 98°, vertical FOV: 52°, diagonal FOV: 116°
3.6 mm, horizontal FOV: 77°, vertical FOV: 42°, diagonal FOV: 91°
6 mm, horizontal FOV: 51°, vertical FOV: 28°, diagonal FOV: 59°
Lens Mount
M12
Illuminator
Supplement Light Type
White Light
Supplement Light Range
Up to 40 m
Smart Supplement Light
Yes
Image Parameters Switch
STD/HIGH-SAT/HIGHLIGHT
Image Settings
Brightness;Contrast;Mirror;Sharpness;Anti-Banding;AGC
Frame Rate
TVI: 1080P@30fps, 1080P@25fps
AHD: 1080P@30fps, 1080P@25fps
CVI: 1080P@30fps, 1080P@25fps
CVBS: PAL/NTSC
Day/Night Mode
Color
Wide Dynamic Range (WDR)
≥130 dB
Image Enhancement
BLC;HLC;Global;HLS
Privacy Mask
4 programmable privacy masks
Noise Reduction
3D DNR/2D DNR
White Balance
Auto/Manual
Interface
Video Output
Switchable TVI/AHD/CVI/CVBS
Alarm
Solid Light Alarm (White Light)
Built-in Microphone
Yes
Event
Motion Detection
4 programmable motion areas
General
Power
12 VDC ± 25%, max. 5.7 W
*You are recommended to use one power adapter to supply the power for one camera.
Material
Metal
Dimension
194.2 mm × 78 mm × 74.5 mm (7.65″ × 3.07″ × 2.93″)
Weight
Approx. 515 g (1.13 lb.)
Operating Condition
-40 °C to 50 °C (-40 °F to 122 °F), humidity 90% or less (non-condensing)
Communication
HIKVISION-C
Language
English
Approval
Protection
IP67
